Characteristics of electrostatic separator

I. Characteristics of electrostatic separator:

www.haibaoseparator.com/electrostatic-plastics-separator-hb1500.html

1. It is suitable for the mixture separation of PA/PBT plastic particles.

2. It can also sort any two kinds of mixed plastics, such as ABS/PS/ submerged PP/PA, flame retardant ABS flame retardant PS, PA/PE/PO.

3. The single sorting accuracy (purity) is high.

4. Damping friction is adopted for the blanking of granular materials to increase the blanking stability of materials.

5. When the crushed materials are separated, it is necessary to crush them, and the crushed particle size is about 20mm, which makes the separation effect reach an ideal state.

6. All the core electrostatic generators are imported brands, which can effectively improve product stability.

7. The control part adopts PLC and touch screen, which is user-friendly and has various functions at a glance.

8. The sorting speed is fast (note: there should not be too much powder in the crushed material).

9. Dry separation mode, no three wastes, no environmental pressure, completely in line with the requirements of the new environmental protection law.

10. If there are more powders and films in the crushed materials, a screening and film removal device can be added.

11. The complete set of equipment is of modular structure, covering an area of about 50 square meters.

12. Rationing feeding, three-stage heating air supply for dehumidification, digital display hygrometer, and internal heating of the machine to prevent moisture.

Second, the electrostatic separator workflow

Pre-separated particles or cleaned and dried crushed materials are fed to the feeding bin → pre-hot air drying → spiral quantitative conveying → mixing of crushed materials → quantitative vibrating feeding → electrostatic primary sorting → mixing of crushed materials → quantitative vibrating feeding → electrostatic secondary sorting (the materials that are not cleaned in this process will be sent back to the feeding bin by pipeline for secondary sorting through positive pressure) → sorted products → bagging.

Third, the electrostatic separator features:

1. Pure physical separation, no pollution, no environmental pressure.

2. The equipment has low power consumption and low operating cost.

3. The operation is simple, and one person can work, which saves labor and is efficient.
